InvisiGrip®

A range of engineered Swivel Cable Toggle end fixings for use with both metal deck and wood form versions of the Spider, for the suspension of building services.

• Fast – below deck install saves time due to swivel toggle technology
• Versatile – universal design allows decision on cable size to be made after the slab is poured
• Strong – up to 715 lbs safe working load, with a 5:1 safety factor
• Simple – supplied in ready to use kits with length of cable with preattached swivel cable toggle and Gripple fastener, making installation straightforward
• Safe – once installed, swivel cable toggle design ensures it cannot be accidentally removed/displaced

For attachment to a variety of substrates using suitable fixings.

• Ideal for use in bracing applications
• Available in sizes No.1, No.2 and No.3 with up to 5:1 safety factor
• Supplied as a ready-to-use kit with Gripple wire rope and hanger
• Available in lengths from 1 m to 10 m (other lengths available upon request)
• Independently certified

For fixing into concrete, steel or wood using gas or power actuated tools, or appropriate screws.

• Ideal for use with Gripple concrete screws for direct soffit mounting
• Available in sizes No.1, No.2 and No.3 with up to a 5:1 safety factor
• Supplied as a ready-to-use kit with Gripple wire rope and hanger
• Available in lengths from 1 m to 10 m (other lengths available upon request)
• Independently certified
• Fire rated version available

For the suspension of HVAC, Mechanical, Lighting & Electrical services in an indoor stationary setting.

• Ideal for use on signage, or exposed services, such as retail and office environments
• Available up to 45kg, with a 5:1 safety factor
• Comes as a ready-to-use-kit with wire rope and Gripple hanger

Specifically designed for fastening through roof cladding.

• Designed to fit 6mm holes
• For supporting up to 45kg of load, with a 5:1 safety factor
• Suitable for every grade of steel
• Ready-to-use kit
• Creates a secure hanger
• Breaking loads may vary dependent on the thickness of steel to which it is attached

For quick and easy attachment to brackets, light fittings and other existing structures.

• Ideal for services that require access or maintenance, such as cable tray and cable basket, especially when used as a Y-Fit
• Available for use with No.1 hanger only
• Comes as a ready-to-use kit with wire rope and Gripple hanger
• Available in lengths from 1 m to 10 m (other lengths available upon request)
• Independently certified

Suitable for a variety of applications that require bolting to brackets or fixtures

• Can be used for horizontal and vertical suspensions
• Available for use with No.1, No.2 and No.3 hangers with up to 5:1 safety factor
• Comes as a ready-to-use kit with Gripple wire rope and hanger
• Available in lengths from 1 m to 10 m (other lengths available upon request)
• Independently certified
• Fire rated version available

For fast quarter turn attachment to Low Profile or Universal Brackets

• Quick – fast, quarter turn attachment to Gripple Brackets
• Multi-use – allows for suspension of services from pre-installed header rails or to provide multi-tier suspension from Gripple Universal Brackets
• Safe – fail safe clip to secure into bracket - prevents unexpected movement
• Compatible – available for use with No. 1, No. 2 and No. 3 hangers
• Ready-to-use – supplied as a kit with wire and Gripple Hanger
• Versatile – available in lengths from 1 to 10 m
• Bespoke – other lengths are available on request

Quick and easy attachment for clips, brackets, light fittings and other existing structures.

• Ideal for services that require access or maintenance, such as cable tray and cable basket, especially when used as a Y-Fit
• Available for use with No.1, No.2 and No.3 hangers with up to 5:1 safety factor
• Comes as a ready-to-use kit with wire rope and Gripple hanger
• Available in lengths from 1 m to 10 m (other lengths available upon request)
• Independently certified

For anchoring into concrete ceilings, metal decking and pressed metal

• Supplied with Drop-in Anchors (as standard) or nuts as required
• M6, M8 and M10 versions available
• Available in sizes No.1 - No.4, with up to 5:1 safety factor
• Comes as a ready-to-use kit with wire rope and Gripple hanger
• Available in lengths from 1 m to 10 m (other lengths available upon request)
• Independently certified
• Available in Stainless Steel (M8)
• Fire rated version available

For fastening through profile roof cladding, light fittings and other cavities

• Ideal when used as a Y-Fit to suspend lighting
• Available for use with No.1, No.2 and No.3 hangers with up to 5:1 safety factor
• Comes as a ready-to-use kit with wire rope and Gripple hanger
• Available in lengths from 1 m to 10 m (other lengths available upon request)
• Independently certified
• Available in Stainless Steel

Aesthetic end fixing ideal for exposed ceiling attachments for lighting and signage.

• Aesthetic fixing for use with a wide range of Gripple hangers
• Ideal when lighting/services are exposed
• Available up to 45 kg SWL with 5:1 safety factor
• Two part construction for fast installation using M6 or Ø4.5 mm c/sunk screws
• Supplied as a ready-to-use kit with wire and a Gripple hanger

For the suspension of HVAC, Mechanical, Lighting & Electrical services in an indoor stationary setting.

• Simple, fast installation that can be easily positioned within the channel or track
• Available for use with No. 1, No. 2 and No.3 hangers
• Comes as a complete kit with wire rope and Gripple hanger

For anchoring into concrete and cracked concrete.

• Ideal for fixing into concrete and cracked concrete
• Shallow anchorage depth of 25 mm
• Available for use with No.1 and No.2 hangers with up to 3:1 safety factor
• Comes as a ready-to-use kit with wire rope and Gripple hanger
• Available in lengths from 1 m to 10 m (other lengths available upon request)
• Independently certified

 For anchoring into concrete.

• Ideal for fixing Gripple hangers into concrete
• Knock into a pre-drilled hole, pull with a claw hammer to set
• Available in sizes No. 1 and No. 2 with up to a 3:1 safety factor
• Comes as a ready-to-use kit with Gripple wire rope and hanger
• Available in lengths of 1 m - 10 m (other lengths available upon request)
• Independently certified

 For attaching directly to existing clips, cable tray, cable basket, brackets and light fittings.

• Provides 9 mm clearance
• Available for use with No.1, No.2 and No.3 hangers with up to 5:1 safety factor
• Comes as a ready-to-use kit with wire rope and Gripple hanger
• Available in lengths from 1 m to 10 m (other lengths available upon request)
• Independently certified
• Available in Stainless Steel

 For quick and secure connection to the Gripple catenary system.

• Visually discreet and lightweight
• Allows for suspension of services exactly where needed
• No tools needed to install
• Available in 1/8" and 1/4" cable diameters, for suspensions up to 220 lbs per span
• C-Clip End Fixing allows for horizontal and vertical adjustment
• C-Clip Cams lock solidly in place, even at angles up to 60°

A shot-fired hanger solution with pre-mounted nail end fixing, for securing installation into concrete or composite metal decking.

• Shot fire into concrete, or concrete over metal deck
• Can be installed with gas and powder-actuated tools
• Quick and easy fastening solution
• Supplied as a ready-to-use kit with Gripple fastener and length
• Please reference submittal data for safe working loads
• Available in lengths of 5 ft - 30 ft as standard

• Designed for use on 24 mm T-Bar grid ceilings
• Quicker manufacture and installation times
• Can be retrofitted
• Available for use with No.1 hanger with up to 5:1 safety factor
• Comes as a ready-to-use kit or in bulk as an accessory
• Available in lengths from 1 m to 10 m (other lengths available upon request)
• Independently certified
